STAGE BLINDER IP RGBW

THÔNG TIN SẢN PHẨM:

Specifications

Light Source: 2 x 110W cool/warm white LED (BL-200 CW/WW)

2 x 125W LED module (BL-200 VW/WW2)

2 x 150W LED module (BL-200 RGBW)

Color Temperature: 2700±200K (BL-200 WW)

2700K (BL-200 WW2)/1200K (Tungsten Mode)

5000±300K (BL-200 CW)

2700~6500K (BL-200 VW)

2000~10000K (BL-200 RGBW)

Beam Angle: 50° (BL-200 CW/WW)

50°(BL-200 VW/WW2)

37°(BL-200 RGBW)

Control

DMX channel: 1/2/4/6 channels (BL-200 CW/WW/WW2)

3/4/4CHr/5/6 channels (BL-200 VW)

6/7/10/4(HSIC) channels (BL-200 RGBW)

Control Mode: DMX512

Firmware Upgrade: Update via DMX link

https://en.acme.com.cn/Info/productdetail/cat_id/271/id/3059

Functional Overview

ACME's STAGE BLINDER IP RGBW is an LED fixture with a classic Blinder appearance and featuring HSIC mode. It has a patented plug-in function, and can be quickly rigged without the need for tools. It can be freely combined with ACME's other STAGE BLINDER IP series fixtures for added creative options, and offers multiple, easily located rotation angles.

Brighter than the traditional audience blinder, with an outstanding variable speed strobe effect, RGBW color options and IPX4 protection rating, the STAGE BLINDER IP RGBW is suitable for large and medium-sized concerts, variety acts and other professional stage or entertainment applications requiring a striking visual impact.

Features

Light Source: 2x 150W LED module
Variable CTO: 2000K - 10000K
Beam Angle: 37°
Unique HSIC mode
Smooth dimming from 0-100%
Outstanding variable speed strobe effect
Fast, tool-free mounting of multiple units in an orientation
Multiple, easily located rotation angles
Ultra-high brightness, brighter than traditional audience blinder
Compact design, excellent thermal design, easy installation
Suitable for large and medium concerts and events of all kinds
Flicker-free management
Dust-proof and oil-proof design
Protection Rating: IPX4
Maximum Connection:
- 120V, 60Hz = 4 sets
- 230V, 50Hz = 8 sets
- TECHNICAL & SPECIFICATION
- Model
  - BL-200 RGBW
  Light Source
  - Light Source: 2x 150W LED module
  - LED life expectancy: 10,000 hours
  Optical System
  - Advanced optical system ensures clear, wide-range wash effect
  - Beam Angle: 37°
  Control and Program
  - 4-button display
  - Display: LCD display
  - Protocols: DMX512, RDM
  - DMX Protocol modes: 4
  - Control channels: 6, 7, 10, 4 (HSIC)
  - Dimmer: 8-bit or 16-bit
  - Firmware upgradeable via DMX link
  Electrical and Connectors
  - Power supply with electronic auto-ranging
  - Input voltage range: 100-240V~ 50/60Hz
  - Power consumption: 235W
  - waterproof power connector in/out
  - Data in/out: 3-pin or 5-pin IP XLR
  Fixture Specification
  - Height: 200mm (6.8”)
  - Width: 215mm (8.4”)
  - Depth: 400mm (15.7”)
  - Weight: 6.8kg (14.9lb)
  Work Environment
  - Maximum ambient temperature: 40°C
  - Maximum surface temperature: 65°C
  - Minimum operating temperature: 0°C
  - Protection Rating: IPX4
  Approvals
  - CE compliant
  Installation
  - Horizontal or vertical mounting available
  - Operating position is universal
  - Foot-stands with 3 locking points
  - Safety Rope Hole
  Included Items
  - Digital User Manual
  Optional Accessories (with item code)
  - Flight case: 3205001171 (8 in 1)
  - Clamp: 2060001632 (C-250B)
  - Hanging bracket：50137301601100
  - Safety cable: 2060000200 (SW-02)
  - DIMENSIONS
  - PHOTOMETRICS
