Functional Overview

The break-through long-life lamp solution from Osram, the SIRIUS HRI 371WLL (or PhilipsMSD PLATINUM 18 R LL) discharge lamp enables the new ACME CHIRON's class-leading 6,000-hour lifespan. Its straight, sharp 2˚ beam makes it a cost-saving investment for a wide range of applications.

Digital position correction technology offers fast and smooth movement. A wide range of mid-air effects is achievable via static gobo wheel(16 gobos) and color wheel (14 colors) in conjunction with two rotating 8- or 24-facet prisms. The impressive 886,000 lux@5m output helps the unit to deliver the utmost in terms of light quality and number of effects.




Features

• Diameter of lens: 146mm

• Long-life design: 6,000-hour lamp life with sleep mode & instant wake-up

• Color temperature: 7650K

• Macro effect and half-tone effect

• Rainbow effect in both directions

• Gobo shaking function for more dynamic visual effects

• 1x static gobo wheelwith 16 gobos plus open

• 1x color wheelwith 14 colors plus open

• 2x prisms: dual 8- and 24-facet prisms, rotatable in both directions and overlayable

• Beam angle: 2°

• Frost: can be used independently

• Motorized focus

• Outstanding strobe effect with variable speed

• Smooth dimming from 0-100%

• Flicker-free management

• Dust-proof and oil-proof design

TECHNICAL & SPECIFICATION

Model

• XP-380 BEAM II

Light Source

• Light Sources (Optional):

  • PHILIPS MSD PLATINUM 18 R LL

  • OSRAM SIRIUS HRI 370W LL

• Life expectancy: 6,000 hours

Optical System

• Advanced optical system ensures clear, sharp image quality

• High-efficiency optical system

• Beam angle: 2°

Control & Program

• 4-button touch panel

• Display: LCD display

• Protocols: DMX512,RDM

• DMX modes: 2

• Control channels: 14, 17

• Pan/Tilt resolution: 16-bit

• Firmware Upgrade via DMX link

Pan & Tilt

• Pan movement: 540°

• Tilt movement: 270°

• Fixation: Pan/Tilt lock

• Automatic Pan/Tilt position correction

• Digital waveform correction technology, ensures accurate positioning of Pan and Tilt, avoidingvariation after high speed movement and reset.

Static Gobos

• 1x static gobo wheel with 16 gobos plus open

Color Wheel

• 1x color wheel with 14 colors plus white

Electrical & Connectors

• Power supply with electronic auto-ranging

• Input voltage range: 100-240V~ 50/60Hz

• Power consumption: 570W

• Power Connector input/output

• Data in/out: 3-pin or 5-pin XLR

Fixture Specification

• Height: 606mm (23.9”)

• Width: 434mm (17”)

• Depth: 344mm (13.5”)

• Weight: 21.2kg (46.7lb)

Work environment

• Maximum ambient temperature: 40°C

• Maximum surface temperature: 65°C

• Minimum operating temperature: 0°C

Approvals

• CE compliant

Installation

• Horizontal or vertical mounting

• Operating position is universal

• 2 pairs of 1/4-turn locking points under base

• 2x fixed clamps with 1/4-turn locks for 50mm truss

• 2x pairs of M12 1/4-turn locking points of removable clamp for 70mm truss

• Safety Rope Hole

Included items

• Digital User Manual

• Power Cable

• 2x fixed clamps with 1/4-turn locks for 50mm truss

Optional Accessories (with item code)

• Raincover: 3033001749

• Flight case: 3205001255 (2 in 1)

• Safety cable:2060001603-A (SW-05)

• Signal line: 3-pin signal line
