LED-PAR100 IP

LED-PAR100 IP

STAGE PAR 100 IP WW

THÔNG TIN SẢN PHẨM:



Specifications

Light Source: 1 x 100W WW/CW LED module

Color Temperature: 3000K/ 5700K

Beam Angle: 9°/15°/20°/25°/30°

Luminous Flux: 4973lm



Control

DMX channel: 1/2/3 channels

Control Mode: DMX512,Manual

Firmware Upgrade: Update via DMX link



https://en.acme.com.cn/Info/productdetail/cat_id/272/id/3066

Functional Overview

ACME's STAGE PAR 100 IP WW features a warm white LED light source, with high CRI, ultra-high brightness and environmental protection. It is designed as an energy-saving replacement for the traditional 1000W PAR lamp. Its IPX4 protection rating provides all-round splash-proof protection. Small and portable, its double hanger design, manually switchable multiple beam angles, 0-100% smooth dimming and variable speed strobe effect make it suitable for a wide range of venues.



Features



  • Light Source: 1x 100W WW LED module
  • Color Temperature: 3000K
  • Luminous Flux: 4973 lumens
  • CRI: ≥90
  • 9°/15°/20°/25°/30° manually switchable beam angles
  • Outstanding variable speed strobe effect
  • Smooth dimming from 0-100%
  • Ultra-high brightness, energy-saving replacement for traditional 1000W PAR
  • Flicker-free management
  • IPX4 protection rating
  • Dust-proof and oil-proof design
  • TECHNICAL & SPECIFICATIONMODEL

    • LED-PAR100 WW IP

    Light Source

    • Light Source: 1x 100W WW LED module
    • LED life expectancy: 20,000 hours
    • CRI: ≥90

    Optical System

    • Advanced optical system ensures clear, wide-range wash effect
    • Beam angle: 9°/15°/20°/25°/30°
    • Total lumen output: up to 4973 lumens

    Control and Program

    • 4-button display
    • Protocols: DMX-512, Manual
    • DMX Protocol modes: 3
    • Control channels: 1, 2, 3
    • Dimmer: 8-bit or 16-bit
    • Firmware upgradeable via DMX link

    Electrical and Connectors

    • Power supply with electronic auto-ranging
    • Input voltage range: 100-240V~ 50/60Hz
    • Power consumption: 108W
    • Power in/out: Power cord out
    • Data in/out: 3-pin or 5-pin IP XLR

    Fixture Specification

    • Height: 422mm (16.6”)
    • Width: 281mm (11.1”)
    • Depth: 418mm (16.5”)
    • Weight: 4.5kg (9.9lb)

    Work Environment

    • Maximum ambient temperature: 40°C
    • Maximum surface temperature: 65°C
    • Minimum operating temperature: 0°C
    • Protection rating: IPX4

    Approvals

    • CE compliant

    Installation

    • Horizontal or vertical mounting available
    • Operating position is universal
    • Supporting feet with 3x locking points
    • Safety Rope Hole

    Included Items

    • Digital User Manual
    • Power Cable
    • Color Frame

    Optional Accessories (with item code)

    • Flight case: 3205001212 (8 in 1)
    • Barn door: 63581138
    • Clamp: 2060001625 (C-150B)
    • Safety cable: 2060000200(SW-02)
    • Signal line: 3-pin or 5-pin IP signal line
    • DIMENSIONS

    • PHOTOMETRICS
