LED-PAR100 RGBA IP

THÔNG TIN SẢN PHẨM:

Specifications

Light Source: 1 x 120W RGBA LED module

Beam Angle: 7°/11.5°/16°/20.5°/25°

Luminous Flux: 1913lm

Control

DMX channel: 4/6/7/8 channels

Control Mode: DMX512,Manual

Firmware Upgrade: Update via DMX link

https://en.acme.com.cn/Info/productdetail/cat_id/272/id/1811

Functional Overview

ACME's STAGE PAR 100 COLOUR IP features an RGBA LED light source, with ultra-high brightness and environmental protection. It is designed as an energy-saving replacement for the traditional 1000W PAR lamp, with its various colored gels. Its IPX4 protection rating provides all-round splash-proof protection. Small and portable, its double hanger design, manually switchable multiple beam angles, 0-100% smooth dimming and variable speed strobe effect make it suitable for a wide range of venues.

Features

Light Source: 1x 120W RGBA LED module
Outstanding color mixing effect
Luminous Flux: 1913 lumens
7°/11.5°/16°/20.5°/25° manually switchable beam angles
Outstanding variable speed strobe effect
Smooth dimming from 0-100%
Ultra-high brightness, energy-saving replacement for traditional 1000W PAR and colored gels
Flicker-free management
IPX4 protection rating
Dust-proof and oil-proof design
TECHNICAL & SPECIFICATION
Model
- LED-PAR100 RGBA IP
Light Source
- Light Source: 1 x 120W RGBA LED module
- LED life expectancy: 10,000 hours
Optical System
- Advanced optical system ensures clear, wide-range wash effect
- Beam angle: 7°/11.5°/16°/20.5°/25°
- Total lumen output: up to 1913 lumens
Control and Program
- 4-button display
- Protocols: DMX-512, RDM, Manual
- DMX Protocol modes: 4
- Control channels: 4, 6, 7, 8
- Dimmer: 8-bit or 16-bit
- Firmware upgradeable via DMX link
Electrical and Connectors
- Power supply with electronic auto-ranging
- Input voltage range: 100-240V~ 50/60Hz
- Power consumption: 110 W
- Power in/out: Power cord out
- Data in/out: 3-pin or 5-pin IP XLR
Fixture Specification
- Height: 422mm (16.6”)
- Width: 281mm (11.1”)
- Depth: 418mm (16.5”)
- Weight: 4.5kg (9.9lb)
Work Environment
- Maximum ambient temperature: 40°C
- Maximum surface temperature: 65°C
- Minimum operating temperature: 0°C
- Protection rating: IPX4
Approvals
- CE compliant
Installation
- Horizontal or vertical mounting available
- Operating position is universal
- Supporting feet with 3x locking points
- Safety Rope Hole
Included Items
- Digital User Manual
- Power Cable
- Color Frame
Optional Accessories (with item code)
- Flight case: 3205001212 (8 in 1)
- Barn door: 63581138
- Clamp: 2060001625 (C-150B)
- Safety cable: 2060000200(SW-02)
- Signal line: 3-pin or 5-pin IP signal line
- DIMENSIONS
PHOTOMETRICS
