LS-1010RGB Laser

THÔNG TIN SẢN PHẨM:

Specifications

Light Source: 10W RGB Semi-conductor laser light

Effects: 40K optical scanner for beam, various built-in laser patterns and animation

Compatible with lasershow software: Pangolin, Phoenix, Mamba

Control

DMX Channel: 17 channels

Control Mode: DMX,ILDA,Sound Active,Auto Play

Firmware Upgrade: Update via DMX link

https://en.acme.com.cn/Info/productdetail/cat_id/295/id/5716

Functional Overview

DIAMONDS II laser lighting, equipped with 10W RGB Semi-conductor, a variety of built-in laser graphics and animation effects, can reach long distance beam effect, the penetration is strong, suitable for many programming software, meet the needs of KTV, clubs, concerts, large-scale venues and other applications.

Features

Effects: 50K optical scanner for beam, various built-in laser patterns and animation
Compatible with laser show software: Pangolin, Phoenix, Mamba
Flicker free management
Dust-proof and oil-proof design
TECHNICAL & SPECIFICATION
Model
- LS 1010 RGB II
Light Source
- Light source: 10W RGB laser light
- Angle: X/Y scanning angle ±30°
Control and Program
- 4-buttons
- Display: OLED display
- Protocols: DMX, ILDA, Sound Active, RDM, SD card control
- DMX Protocol modes: 2
- Control channels:27/52
- Upgrade the firmware via SD card control
Electrical and Connectors
- Power supply with electronic auto-ranging
- Input voltage range: 100-240V 50/60Hz
- Power consumption: 185W
- Power Connector input
- Data in/out: 3-pin and 5-pin XLR
Fixture Specification
- Width: 230mm (9.1")
- Depth: 320mm (12.6")
- Height: 183mm (7.2")
- Weight: 13.5kg(29.8lbs)
Work Environment
- Maximum ambient temperature: 40°C
- Maximum surface temperature: 65°C
- Minimum operating temperature: 0°C
Installation
- Horizontally or vertically mounting are available
- Operating position is universal
- The feet support with 1 locking points
- Safety Rope Hole
Included Items
- Power Cable
- User Manual
- DIMENSIONS
