M600W Sound Source

M600W Sound Source

M600W Sound Source

Technical & Specification

System data

  • Frequency range：50Hz-18kHz,-3dB
  • Maximum output sound pressure level /(power limit) ：LF/131dB ; HF/132dB
  • Sensitivity（1W/1m）：LF/99dB ; HF/107dB

Loudspeaker data

  • Rated power（AES）：LF/400W;HF/80W
  • Program power：LF/800W;HF/160W
  • Nominal impedance：8Ω
  • LF unit: 15"（3"Voice Coil）
  • HF unit: 3" (Compression driver )
  • Horizontal spreading angle: 40°
  • Vertical spreading angle: 60°
  • Power amplifier:Low.CH/600W; Hi.CH/180W
  • Automatic voltage selection:AC100-240V, 50/60HZ
  • DSP filter:FIR or IIR frequency crossover filter
  • DSP pre storage:8 program pre-stored settings
  • DSP control:RS485 communication
  • Audio connector:Balance-XLR type input and /link-output
  • AC power outlet:2X powerCON
  • Mode selection:Microphone input or audio LINE-input

Dimensions / weight

  • Finish material：Black PU abrasive-resistant paint
  • Cabinet dimension(WxHxD）mm:588x367x441mm
  • Net Weight : 24Kg



    CHI TIẾT KỸ THUẬT

    Model no.

    M600W

    Rated power

    LF/400W;HF/80W

    Maximum power

    LF/800W;HF/160W

    Nominal impedance

    8Ω

    Sensitivity

    LF/98dB ; HF/107dB

    Maximum output sound pressure level

    LF/130dB ; HF/132dB

    Frequency response

    50Hz-18kHz,-3dB

    Woofer

    15"(3"Voice Coil)

    Tweeter

    3" (Compression driver )

    Horizontal spread angle

    80˚

    Vertical expansion angle

    80˚

    Connection ports

    2x4-points Speakon®

    Connection number

    1+/1-(INPUT),2+/2-(Link)

    Cabinet material

    Black PU resistant paint

    Dimensions

    588x367x441mm

    Net Weight

    22 Kgs
