RL0.5 SUB protection bag/cart

RL0.5 SUB protection bag/cart

RL0.5 SUB protection bag/cart

Technical & Specification

System data

  • Frequency range：45Hz-18KHz(-3dB)

  • Maximum output sound pressure level ： LF/141dB；MF/143.6dB；HF/143.9dB

  • Sensitivity（1W/1m）： LF/102dB； MF/108.5dB； HF/114.5dB

Loudspeaker data

  • Rated power：LF1/1000W；LF2/1000W； MF/800W；HF/220W

  • Program power：LF1/2000W；LF2/2000W； MF/1600W；HF/440W

  • Nominal impedance：LF1/8ohm；LF2/8ohm MF/8ohm；HF/8ohm

  • LF unit：2x12”

  • MF unit: 4x6.5”

  • HF unit: 2x3" (Compression driver )

  • Connection index ：1+/1- (LF1)；2+/2- (LF2)；3+/3- (MF)；4+/4- (HF)

  • Connectors：

    • 2x 8-points Speakon®

    • 1xLink cable

  • Directivity：

    • H(90 ° -120°)

    • V(Dependent upon number of elements and line source curvature)

Dimensions / weight

  • Finish material：Black PU abrasive-resistant paint

  • Cabinet dimension（WxHxD）： 1178x390x587mm

  • Net Weight : 102 Kg

  • Dimensions

    CHI TIẾT KỸ THUẬT

    Cart Dimensions

    858x361x906mm

    Net Weight

    46.3 Kgs

    Collision transport bag size

    730x1350x800mm

    Weight

    6.5 Kgs
