THÔNG TIN SẢN PHẨM:



Specifications

Light Source: 6 x 1W RGB Semi-conductor laser light

Effects: 6 beams of parallel light, the R/G/B mixed into different colors of light beam, clear light, high straightness, built-in laser show



Control

DMX Channel: 5/20 channels

Control Mode: DMX, Auto Play

Firmware Upgrade: Update via DMX link





Functional Overview

The ACME GLORY FOLLOWSPOT II features an OSRAM Lok-it! 1000/PS Brilliant 1000W 6000K lamp, to project a crisp 6000K white light for exhibition and display applications, as well as a warm 2700K for stage performance. It has an adjustable iris range from 5% to 100%, a zoom ratio of 1:4 (5˚ to 20˚) and manual focus, plus a custom tripod which enables smooth pan and tilt movements. The GLORY FOLLOWSPOT II has a comfortable and stable feel for tracking performers. Not only can it project light with high CRI (>90), it also includes 7 different color temperature filters in the compact body, making a CCT range from 2700K to 5600K available by manual selection on the display, offering more possibilities for various applications and an excellent tracking effect. What’s more, a 5-slot manual boomerang is attached to the front of the unit for quiet color changing.



Features

  • Manual focus
  • Zoom range: 5˚-20°
  • CRI>90
  • 7 independent color temperature filters
  • Smooth dimming from 0-100%
  • 5-100% iris
  • Tripod and color gel frame as standard
  • Flicker-free management
  • Dust-proof and oil-proof design

TECHNICAL & SPECIFICATION

Model

  • XP-1000FS II



Light source

  • Light source: Osram Lok-it! 1000/PS Brilliant
  • Life expectancy: 750 hours
  • CRI:>90



Optical system

  • Advanced optical system to ensure clear, sharp image quality
  • High-efficiency optical zoom (ratio 1:4)
  • Beam angle: 5˚-20°



Control and Program

  • 4-button touch panel
  • Display: LCD display
  • Electronic ballast



Electrical and Connectors

  • Power supply with electronic auto-ranging
  • Input voltage: AC 230V, 50/60Hz
  • Power consumption: 1181W
  • Power cord out



Fixture Specification

  • Height: 337 mm (13.2")
  • Width: 418 mm (16.5")
  • Depth: 1032 mm (40.6")
  • Weight: 43.2kg (95.2lb) excluding tripod; 60kg (132.2lb) including tripod



Work Environment

  • Maximum ambient temperature: 40°C
  • Maximum surface temperature: 65°C
  • Minimum operating temperature: 0°C



Installation

  • Horizontal mounting on tripod
  • Operating position is universal
  • Safety Rope Hole



Included Items

  • Power Cable
  • Digital User Manual
  • Tripod
  • Color Gel frame



Optional Accessories (with item code)

  • Flight case: 3205001163 (1 in 1)

DIMENSIONS

PHOTOMETRICS
