EVOX 12

EVOX 12

EVOX 12

THÔNG TIN SẢN PHẨM:



EVOX 12 is the most powerful line-source in its class and offers a particularly profound and dynamic reproduction at high levels due to the built-in 1400W power amplifier. The top section has eight high performance neodymium 4 “full-range transducers with a phase plug. As a result, the EVOX 12 has a significantly increased low-mid playback at a constant level with a wide dispersion for the highs. The 15” subwoofer delivers powerful bass sound to reinforce a big party or the kick drum of a live band. Despite high performance, the enclosure is very compact, and thanks to integrated wheels and extendable handle very easy to transport.

    CHI TIẾT KỸ THUẬT

    EVOX TWO-WAY ARRAYS

    EVOX array design features constant horizontal directivity coverage of 90°x30°, offering a perfect listening experience to the audience. The vertical array design is progressively shaped to guarantee a correct listening from the first row and to avoid a high frequency beaming typical of straight array



    LIVE SOUND

    Extensive testing with instruments and voices during the design process as well as power and reliability testing make the EVOX system the perfect workmates for solo musicians or bands.



    DJS

    Extremely deep response, precise low frequency control and incredible audio quality, easy to transport and quick to set up. EVOX is without any doubt a smart choice for DJs.



    CONFERENCES

    Extraordinary clarity and dynamic of vocal reproduction, both at low and very high levels. EVOX is a great tool for conferences and speeches.



    FEATURES

    1400 Watt

    130 dB max SPL

    40 Hz 20 kHz frequency response

    15" Woofer

    8 x 4" neodymium full-range woofer

    90° x 30° slightly tilted pattern control

    Innovative DSP processing

    Pole mountable, easy set-up and transportation



    ACOUSTICAL SPECIFICATIONS

    Frequency Response -3 dB:40 Hz ÷ 20 Hz

    Max SPL:130 dB

    Horizontal coverage angle:90°

    Vertical coverage angle:30°

    Fullrange:8x4.0", 1.0"v.c.

    Woofer:15", 3.0" v.c.



    INPUT/OUTPUT SECTION

    Input connectors:Jack-XLR male

    Output connectors:XLR female

    Input sensitivity:-2 dBu / + 4 dBu



    PROCESSOR SECTION

    Crossover frequencies:180 Hz

    Protections:thermal, rms

    Limiter:Soft limiter

    Controls:Volume, EQ



    AMPLIFIER SPECIFICATIONS

    Total power:1400 W PEAK

       . High frequencies:400 W PEAK

       . Low frequencies:1000 W PEAK

    Total power:700 W RMS

       . High frequencies:200 W RMS

       . Low frequencies:500 W RMS

    Cooling:Convection

    Connections:VDE connector



    CABINET

    Cabinet Material:Baltic birch plywood

    Handles:2 side, 1 top

    Pole Mount/Cap:Yes

    Colour:black



    PHYSICAL SPECIFICATIONS

    Height:2220/87.4 mm/inch

    Width:410/16.14 mm/inch

    Depth:560/22.05 mm/inch

    Net Weight:36.4/80.24 kg/lbs
